TB45, TB88, TB68, TB38, TB38C series


Warning! Remember to fill out the form located at the bottom of this page.
If you do not receive an answer in 48 hours (working days), you can write us directly to our e-mail:

From the day you receive the pickup, you have 20 days to try it on your own amplifier and if you do not satisfied, we will refund the total amount paid in Paypal once you send us your purchase properly packed in their original packaging. In addition, according to the law, all products are guaranteed.
String Pickups
TB45 standard series

TB45/CC.

Instruments: (sitar, acoustic guitar, classical guitar, and similar). Also small melodic percussion (hang drum).
Contact surface: 21mm. x 11.5mm.
Impedance: 12K ohms aprox. (1Khz).
Cable pickup: Custom according to client.
Approximate measurements:
5 a 20cm. Guitar, lute, sitar, etc.
17cm. Violin and viola.
30cm. Cello.
40cm. Double bass.
Output cable to amplifier: 3m. shielded with RCA and Jack 1/4".
Fixing: double sided tape included.

TB45/CC: 85 €
With female RCA connector plus 3m. shielded cable. RCA + JACK 1/4" to amplifier.


Universal Pickup TB88 series
Electric sound = Acoustic sound

The professional TB88 series offer you a much flatter response than standard series and high output voltage. For this reason, in most cases, it is not necessary to use a preamplifier.
Classic guitar with the TB88/CR pickup Classic guitar with the TB88/CR pickup

TB88/CR.

Instruments: Any stringed musical instrument and small percussion.
Contact surface: 20mm. x 12.5mm.
Impedance: 12K ohms aprox. (1Khz).
Output cable to amplifier: 3m. shielded with RCA and Jack 1/4".
Fixing: double sided tape included.


TB88/CR: 88 €

Percussion pickups
TB68 series

TB68/1P. One pickup percussion.

Size: diameter: 22mm. height: 6.5mm. aprox.
Impedance: 25K ohms. (1Khz).
Pickup cable: shielded 0.3m. (Fixing the RCA connector with velcro).
Output cable to amplifier: 3m. Shielded with RCA and Jack 1/4".
Fixing: self adhesive tape included.

TB68/1P: 58 €



TB68/2P. Two pickups percussion.

Size: diameter: 22mm. height: 6.5mm. aprox.
Impedance: 12K ohms. (1Khz).
Pickup cables: Blindado 0.4m. x 2u.
Output cable to amplifier: 3m. Shielded with RCA and Jack 1/4".
Fixing: self adhesive tape included.

TB68/2P: 92 €


TAV Pickup installed on the tabla TAV pickups. Pickup TB68/1P

TB68/PK. One pickup percussion.

Size of the fixing tab: 16mm. x 13mm.
Impedance: 24K ohms. (1Khz).
Fixing: by tab or self-adhesive tape
Cable pickup: shielded 0.3m. with RCA connector
Output cable to amplifier: 3m. Shielded. With RCA and Jack 1/4".
Fixing: self adhesive tape included.

TB68/PK: 58 €


Detail of the pickups installed.

TB68/Tablas.

Two pickups: tabla and baya.
Size of the fixing tabs: 16mm. x 13mm. 22mm. x 18mm.
Impedance: (Pickups in parallel with micromix) 12K ohms. (1Khz).
Micromix: tabla/baya.
Pickup cables: 0.45m. Tabla and 0.3m. Baya.
Output cable to amplifier: 3m. Shielded with RCA and Jack 1/4".
In some cases a preamplifier is necessary.

TB68/Tablas: 92 €

Bowed String Pickups
TB38 series

TB38/VSA. Violνn and viola pickup.

Active area: to support the left foot of the bridge: 12,5mm. x 5,5mm. aprox.
Impedance: 28K ohms. (1Khz).
Cable pickup: Shielded 12cm. with RCA connector with self-adhesive "velcro".
Output cable to amplifier: 3m. shielded with RCA and Jack 1/4".

TB38/VSA:  73 €


TAV pickup. The TB38/VSA violin pickup under the bridge TAV pickup. The TB38/VSA violin pickup under the bridge

TB38/CH. Cello pickup.

Active area: to support the left foot of the bridge with meassures from 24 to 27mm. x 12mm.
Impedance: 24K ohms. (1Khz).
Output: by RCA connector.
Output cable to amplifier: 3m. Shielded with RCA and Jack 1/4".

TAV pickups. TB38/CH

TB38/CH: 78 €


TAV Pickups - Cello TAV Pickups - Double bass

TB38/CB. Double bass pickup.

Active area: to support the left foot of the bridge: 23mm x 46mm.
Impedance: 12K ohms. (1Khz).
Output: by RCA connector.
Output cable to amplifier: 3m. Shielded with RCA and Jack 1/4".

TAV pickups. TB38/CB

TB38/CB: 78 €

Custom Pro Pickups

guembri guembri + pickup

TB38/Custom. All instrument with the mobile bridge.

Design according to the instrument and customer specifications for all types of musical instrument with the mobile bridge: viola, viola de gamba, sitar, surbahar, cello, double bass, guembri, etc.

  1. A photo of the instrument.
  2. Dimensions of the foot of the bridge.
  3. Length of the pickup cable to the output connector.

TB38/Custom pro: 110 €

Fill the form with your data and, if you have chosen a model as or want any further modification (cable length, connector type, etc.) describes, in detail, your edits.


Finally, send your order. A soon as possible you will receive, via email, your online purchase plan, including confirmation and stock price, payment mode and delivery. If you agree, a few days you get the pickup at your house properly packed.
